Phase One DF, P40+ and Sensor Plus Combination

[Guy Mancuso]

As most folks know here I received the new DF body and upgraded to the P40+ from the P30+ which at the time I did question my thought pattern on upgrading or just spending the money and get a Canon or Nikon. Which to some degree made a lot of sense but I am a very stubborn person as well and my desire to shoot 35mm again is null. I really like shooting MF and my biggest thing is if I am going to work at this until the box lid closes than I want to enjoy shooting and after 35 years of shooting I want as much pleasure out of it as i can get now. Okay that was the stubborn part and reality is it actually makes some sense at least to me it does.

Now after a heavy shoot in which let's face it shooting runway and stage work is not in favor of MF shooting. But you pick your poison and get to work and that I did with the P40+ and using Sensor Plus. I did not need 40 mpx to shoot these images but the ability to shoot 10 mpx on stuff like this led me straight in the direction of the P40+ with Sensor Plus since to me this makes a load of sense when I get a gig like this and with a switch of the ISO i can jump right into smaller files , faster processing and the ability to pick my resolution on what I am shooting plus the biggy get high ISO images with low noise. Even in the middle of this kind of shoot if I thought I needed the big honking files than it was a easy switch over.

Let's talk first about the DF camera over the AFDII and III models. Fast does not begin to describe the difference. Now i should clarify that statement it's faster for sure and for some folks it may not seem like a big difference BUT BUT BUT when you shoot very fast and rely heavily on timing the DF comes to the rescue. The shutter lag now is certainly a big improvement to me. When shooting this runway stuff I can actually shoot when one leg is in the correct position when the models are walking and this is very important in runway as it gives the body the correct lines. Before it was hard to nail it at will , now with the DF the shutter lag is so minimal it becomes a much more accurate and faster cam. The AF system has improved as well. Many shots here are shot with a Mamiya 300mm AF 4.5 lens on a monopod and focusing set for continuous and as a model comes out from stage right to the end of the T in the staging it's about a 75 foot stroll. The AF followed focus the whole time and never left me guessing I was nailing it. To me very much inline with what we are used too with Canon although slightly slower it still did the job and overall responsiveness is much closer to 35mm than MF now if you catch my meaning. The bar on speed has gone up

One nit that I found I did not like was trying to use the rear focus button, I found the button not big enough to always be using it . Now that maybe me and my personal preference but it is their for you if you choose to go this route. Also I have found great improvement with battery life on the DF and going far longer with the ni-cad batteries. I shot one day about 1400 images with review on for 5 seconds and the indicator never dropped down. I switched to a new pack the next day just because and not that I had too. Obviously I did not measure this exact improvement but it is there for sure and i also noticed my backs battery improvement as well over the P30+ so must be some energy savings going on with wake up and such as the P40+ and P65+ do handle that differently and maybe someone from Phase can answer as to why that is but the fact remains I see some battery improvement, all good in my book.

Overall on the DF with the grip improvement as well that it is really a winning cam now. But Like i said on paper it may not seem so but with shooting like this I really come to like it so much better over the AFD-III and can really feel the improvement. Personally I am a feel person with cams and they have to feel good both physically and mentally for me and this is punching my ticket very nicely so far. Could their be more improvement of course but i feel Phase finally has a cam that at least brought the bar up enough to feel more 35mm DSLR performance and that is a good thing.

The P40+ and sensor plus. I know much has been said about this and some folks feel it is a gimmick or maybe never use it. Well I bought it exactly for this technology and for jobs like this when i can run the ISO's high and not deal with 40 mpx files as well. I can do a lot of talk on this area alone but I think images are really the answer here. But to me I am getting extremely clean ISO 800 and the ISO 1600 have a touch of noise but in these shots would be the WORST case scenario as well. All tungsten lighting and very contrasty lighting with a lot of shadows and mid tones around that really would show the noise area's very much. At 1600 it handled this far better than I thought it would. In reality I shot all of the beginning of the show which are more groups like singers , dancers and team fashion at ISO 1600 because the light varied with each setup coming down the runway and all the single shots of models i used ISO 800 because the light was constant all the way through those events and even shot on manual in those and AE on the team stuff since the light varied. Basically I adapted to what was going on as we should do that and the combination of gear here handled all that very well. I shot handheld on all the team stuff with varies lenses 45, 80 and 150 and on the single runway shots used a 300mm on a monopod

[Guy Mancuso]

These are all ISO 1600 with Sensor Plus handheld under tungsten lighting. Lenses varies from 45d, 80d and 150d. All processed in C1 with noise levels at 20 for luminance and color at 60.

[Guy Mancuso]

These are all ISO 800 with Sensor Plus with monopod under tungsten lighting. Lenses 300mm AF 4.5 shot at 5.6. All processed in C1 with noise levels at 10 for luminance and color at 30.

[Guy Mancuso]

These are all young models and actors trying to break into the business. I obviously have another 1000 images but hopefully this will give you a nice broad section on Sensor Plus and high ISO abilities.

[Guy Mancuso]

One thing I forgot to mention is the back is also faster in Sensor Plus mode, maybe Doug can address the speed difference between full resolution and sensor plus in speed gain of the back itself.

[Guy Mancuso]

I did not try ISO 3200 but I do have some underexposed 1600 that I can process up to normal and maybe give us some indication of those noise levels. I know 3200 is noisy from my earlier testing but for MF shooting I am very impressed we can get this high without jumping into a 35mm system which obviously will do a better job at much higher ISO but we are back to apples and oranges and i don't want to shoot 35mm again if i can help it. If the need comes than I will rent but at this point i don't see doing that anytime soon.

[dougpetersonci]

Originally Posted by Guy Mancuso

One thing I forgot to mention is the back is also faster in Sensor Plus mode, maybe Doug can address the speed difference between full resolution and sensor plus in speed gain of the back itself.

The tech specs state 1.2 fps for full-size 40 megapixel files and 1.8 fps for sensor+ sized 10 megapixel files. This applies to the DF body and 40+ assuming the 40+ has the latest firmware. However, I've not yet done a test specific to speed, especially sustained shooting speed to see how closely and consistently the real world performance comes to this spec.

For sure it is very fast in sensor+ mode compared to any experience I've had shooting medium format.

Of note: P+ backs very rarely hit a buffer in testing and even more rarely in real-world shooting. While a 5D mark II, for example, can shoot very fast frames-per-second it can only do so for a relatively short burst before hitting a buffer. My only test with a DF body and 40+ in sensor+ was about 40 frames in a row at uniform very-fast speed before I voluntarily stopped (it was the first unit in the country and I didn't want to crank up the shot count needlessly). Depending on what you're shooting you may long for the extremely fast frame rate of a high-end dSLR or you may long for the unlimited buffer depth and predictable/consistent speed of a 40+; neither is "better" they are just different takes on speed. This takes on an entire other dimension when you're shooting tethered since a P40+ shooting tethered is significantly faster and more consistently fast shooting tethered both in terms of sustainable frames per second and in terms of how quickly a rough and final preview appear on the screen.

Also of note: because of the way P+ backs handle noise by collecting a black capture there is often a slight delay after the very first shot at a new shutter speed. For most styles of shooting this slight delay would never be noticed, but if you're shooting something like runway and really need the most consistent fast speed possible you should set the body to time-priority and take a "test" shot first. Every shot after that will be at the maximum speed of the system.

I like notes: you'll want extremely (pun intended) fast cards if you're shooting sustained fast speeds.

Doug Peterson (e-mail Me)
__________________
Head of Technical Services, Capture Integration
Phase One, Leaf, Cambo, Canon, Apple, Profoto, Eizo & More
National: 877.217.9870 *| *Cell: 740.707.2183
Newsletter: Read Latest or Sign Up
RSS Feed: Subscribe
Buy Capture One at 10% off
Personal Work

[Guy Mancuso]

Thanks Doug and yes i did run into some buffer issue with some old cards with 30mb transfer speeds. My feeling is Phase tuned this back to the newer cards with there firmware and I promptly sold my old cards and just purchased 3 new Sandisk Extreme Cards 16gb at the 60MB per second transfer speeds. I have not formally tested them but I did lay on the release for about 20 frames full res and no issues. Highly recommend at least these new cards at 60MB per second and you could even shoot the 90 ones

[Jack Flesher]

Those 1600 frames are amazingly clean -- in fact, at least in these onscreen jpegs, I cannot see much difference over the 800 shots. Impressive!

[Guy Mancuso]

Well if you have to save yourself you can although they are starting to go at 1600 pushed a full stop up in exposure they are holding on okay. Not sure i would do this on a regular basis but it will work. Both shot with the 150 D which also saves the day since it is so sharp. Visually it works

[RayM]

Guy, thanks for taking the time to post these. You've shown what the back can do when you're in a "live ammo" situation, and the targets are moving, the now-customary place for 35mm size DSLRs. I'm really very impressed. The focus looks terrific, the level of noise is really good too. And the look of the lenses themselves look really good too.

How much work did you have to do with color?

Ray

[Guy Mancuso]

Very little work on the color Ray. Pretty much just WB, now the lighting guy did throw in a few curve balls as you will see in a couple shots he had a underlining blue light happening on the single runway shots. This is not normal for a lighting guy to do and wondering what he was smoking actually . Usually it is a stage wash of white focused on the runway itself. Bozo was playing around with some blue and in the shadows you can spot some blue. Not much I could do there. Also in these last two he did not have enough white light going on so again he had some blue for effect and it does effect the colors slightly on these last two. I did not try and correct it though and left it as a group WB from the beginning which was set for tungsten on the back. I may have touched the kelvin for slightly warmer by 200 but sometimes perfect is not what you want either. Obviously lot's of ticky lighting going on especially on the groups or teams which looks great visually for the audience but can be a shooters nightmare. I cursed him a few times. LOL

[Guy Mancuso]

Here Ray is one where the lighting guy was getting a little out of control. Obvious blue light hitting the top of her head and at certain angles it would show up in the shadows under the chin. He did this for part of this section of what we call Fashion Runway for the competition. Here he was not my best friend.

[Guy Mancuso]

The underlining fact here is with some of the new backs and bodies we are approaching 35mm land and getting the speed of camera and back that we may have lacked in the past. As the technology improves it is becoming more apparent maybe to the OEM's that we are not just after MPX which we all know is not the main selling point, we need the speed and the ability in our systems to have this kind of flexibility. For someone like me that relies on one system obviously this is very important to me in the variety of shooting gigs I get, so having a system that can do many things and do them well is really a major plus. I really have to tip my hat to Phase on this for maybe recognizing these needs. Sure we all want more and more improvements no question and we just need to keep reminding the OEM's of our real needs. I went through 3 backs to get to the P40+ and i truly liked them all for what they did but this one is hitting some major check marks and i really like it so far.

[RayM]

Guy, Really pleased to hear that there was minimal work required from you on the color. Outstanding really, especially with the guy on the lights trying his hardest to make it difficult.

I'm pretty confident that I could not have done a shoot like this with my Contax equipment, it would have all been moving too fast for the camera to give me anything even close to what you were able to do. This is just so exciting, isn't it? Aren't you relieved that this camera/back combination is able to contribute results like this?

Can't wait for mine! Ray

[Jack Flesher]

Those ISO 3200 effective, pushed 1600 shots are amazingly clean...

[Guy Mancuso]

Originally Posted by RayM

Guy, Really pleased to hear that there was minimal work required from you on the color. Outstanding really, especially with the guy on the lights trying his hardest to make it difficult.

I'm pretty confident that I could not have done a shoot like this with my Contax equipment, it would have all been moving too fast for the camera to give me anything even close to what you were able to do. This is just so exciting, isn't it? Aren't you relieved that this camera/back combination is able to contribute results like this?

Can't wait for mine! Ray

Yes very relived and i did test this back twice before finally deciding over the P30+ which is also a excellent back but that back I had to deal with full resolution. But still the only back that does 1600 at full resolution and it is pretty clean. It was a tough choice but sinking money in a Nikon or Canon system was something I wanted to avoid also and I think the P40+ is the best bang for the buck right now and for existing Phase owners a very cost effective upgrade. I'm very pleased so far and think it was a excellent choice what I did not count on was the DF at even the small improvements to it on paper meant a lot more in real world.

[RayM]

Guy, what I hear from you in your last post is that it seems like a couple of things are coming together in this newest generation of Phase backs and the new DF. It's like we finally don't have to pick between speed OR big sensor. Really terrific. Ray

[Guy Mancuso]

Exactly Ray you get both and make no mistake shooting at full resolution also is very very quick. The AF is still faster and the back at full resolution is one of the fastest backs out there and ISO 800 full resolution is very very good. I like the options you have in this back. Just makes the whole thing more flexible given your shooting situation. Hopefully yours is on it's way from Denmark.

[RayM]

Guy, I think in retrospect, the "responsiveness" thing is what I've been missing in the Contax. When my subject was standing still, I felt really good about what I could do with the camera and lenses, and I was very pleased with the product. The relative sluggishness of the autofocus and the need to wake up the camera after a few seconds, even though I got used to it, I wish it would have been otherwise.

Also, part of what I've been afraid about is how well the mamiya lenses will match up with my contax zeiss lenses, especially the macro, as my go-to lens is the macro. BUT, from what I've been seeing posted, and what I've read from you and others, the D lenses appear to be very good. Imagine that, I might be happy with the whole kit!

[Guy Mancuso]

Actually the Mamiya 120 Macro is rated maybe the best macro around. I read that somewhere and was a bit surprised since there are many very very good ones.

All the D lenses i have are very very good don't let that Mamiya reputation fool ya.

[RayM]

I hadn't heard the thought about the Mamiya macro, so that's great to hear, Guy. Really hope to get my hands on it soon.

[aprillove20]

Stunning set of photos, I like the composition.

[rwsphotography]

Guy,

At first I read through these threads thinking "why would I spend that kind of money on the P40+ when I have the equivalent in a faster and easier to pack DSLR?" Then I saw this on the luminous landscape site:

http://www.luminous-landscape.com/1p...sol-duc1.shtml

and I thought "Wow, f64 just like the founders....!"

It's clear that it's about glass and MF and when you want to capture a moment, image, vision, work of art, it requires some processing, glass and pixels to make it happen.

I won't be re-investing soon (my old Hassey still provides enjoyment while the silver oxide is still available), but I could get convinced. How about the new Leica S2?

Thanks for the knowledge, dialogue and camaraderie!
